5–62 Maintenance and Service Guide
Removal and Replacement Procedures
5.19 USB Board
1. Prepare the computer for disassembly (Section 5.3) and
remove the following components:
❏ Hard drive (Section 5.4)
❏ Mini Card compartment cover (Section 5.8)
❏ Optical drive (Section 5.9)
❏ Keyboard (Section 5.10)
❏ Switch cover (Section 5.11)
❏ Display assembly (Section 5.12)
❏ Top cover (Section 5.13)
USB Board Spare Part Number Information
USB board 417085-001
