5–26 Maintenance and Service Guide
Removal and Replacement Procedures
3. Turn the computer display-side up with the front panel
toward you.
4. Open the computer as far as possible.
5. Slide the keyboard 1 back to release the tabs on the front of
the keyboard from the top cover.
6. Lift the rear edge of the keyboard 2 and swing it forward
until it rests on the palm rest.
Releasing the Keyboard
