HP 2510p - Compaq Business Notebook Maintenance And Service Guide

15.4-in, WSXGA+ display specifications
Metric U.S.
Dimensions
Height
20.7 cm 8.15 in
Width 33.1 cm 13.03 in
Diagonal 39.1 cm 15.39 in
Number of colors Up to 16.8 million
Contrast ratio 200:1 (typical)
Brightness 180 nits (typical)
Pixel resolution
Pitch
0.197 × 0.197 mm
Format 1680 × 1050
Configuration RGB vertical stripe
Backlight CCFT
Character display 80 × 25
Total power consumption 7.0 W
Viewing angle +/-40 horizontal, +/–50° vertical (typical)
106 Chapter 6 Specifications

HP 2510p - Compaq Business Notebook Specifications

General

Display	12.1-inch WXGA (1280 x 800)
Graphics	Intel GMA X3100
Processor	Intel Core 2 Duo U7600
RAM	Up to 4 GB DDR2 SDRAM, 667 MHz
Storage	80/120 GB 5400 RPM
Operating System	Windows Vista Business
Battery Life	Up to 6 hours
Wireless	Intel PRO/Wireless 3945ABG or 4965AGN
Dimensions	28.2 x 21.4 x 2.35 cm
Ports	3 USB 2.0, VGA, headphone/microphone jacks, docking connector
Optical Drive	External (optional)
