Remove the speaker assembly:
1. Position the computer right-side up, with the front toward you.
2. Disconnect the speaker cable (1) from the system board.
3. Remove the two Torx PM2.5×7.0 screws (2) that secure the speaker assembly to the base
enclosure.
4. Remove the speaker assembly (3) from the base enclosure.
Reverse this procedure to install the speaker assembly.
System board
NOTE: All system board spare part kits include replacement thermal material. The Thermal Material
Kit is also available using spare part numbers 413706-001 (for use in all countries or regions except
Japan and Asia countries and regions) and 445853-001 (for use only in Japan and Asia Pacific countries
and regions).
Description Spare part number
System boards for use in all countries and regions except Russia and China:
For use in HP EliteBook 8530w models with Intel Core2 Extreme Quad-Core processors 500906-001
For use in HP EliteBook 8530w models with Intel Core2 Extreme Dual-Core processors 500905-001
For use in HP EliteBook 8530p and 8530w models with Intel Core2 Duo processors 500907-001
System boards for use only in Russia and China:
System board for use in HP EliteBook 8530w models with Intel Core2 Extreme Dual-Core processors 510349-001
System board for use in HP EliteBook 8530w models with Intel Core2 Extreme Quad-Core
processors
510350-001
System board for use in HP EliteBook 8530p and 8530w models with Intel Core2 Duo processors 510348-001
88 Chapter 4 Removal and replacement procedures
