Modem module
NOTE: The modem module spare part kit does not include a modem module cable. The modem
module cable is included in the Cable Kit, spare part number 495064-001. See
Cable Kit on page 27
for more Cable Kit spare part number information.
Description Spare part number
Modem module 461750-001
Modem module for use in Asia Pacific and Japan 461750-011
Before removing the modem module, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 44).
5. Remove the following components:
a. Hard drive (see
Hard drive on page 50)
b. Optical drive (see
Optical drive on page 46)
c. Keyboard (see
Keyboard on page 60)
Remove the modem module:
1. Turn the computer right-side up, with the front toward you.
2. Remove the Phillips PM2.0×4.0 barrel screws (1) that secure the modem module to the system
board.
3. Disconnect the modem module (2) from the system board by lifting it straight up.
Component replacement procedures 63
