HP 2510p - Compaq Business Notebook Maintenance And Service Guide

Category Description HP EliteBook
8530p
Notebook PC
HP EliteBook
8530w Mobile
Workstation
Customer-accessible √ √
Serial ATA √ √
12.7-mm tray load √ √
Supports the following drives:
●
DVD±RW and CD-RW Super Multi DL
Combo Drive with LightScribe
●
Blu-ray Disc ROM with SuperMulti DVD+/-
R/RW DL Drive
●
DVD-ROM Drive
√ √
Diskette drive Supports external USB diskette drive only √ √
Supports boot from external USB diskette drive √ √
Microphone Integrated dual-array microphone √ √
Audio HD audio - ADI 1984A √ √
Webcam Integrated 2.1-megpixel webcam with business
card reader support
√ √
Modem 56K V.92 1.5-in data/fax modem with digital line
guard
√ √
HD audio interface √ √
Ethernet Intel 10/100/1000 network interface card (NIC)
with iAMT
√ √
S4/S5 wake on LAN: DC - no √ √
S4/S5 wake on LAN: AC - yes √ √
NIC power down technology √ √
Wireless Integrated WLAN options by way of wireless module:
Three WLAN antennas built into display
assembly
√ √
Support for no WLAN option √ √
Support for the following WLAN formats:
●
Intel 802.11a/b/g/n
●
Intel 802.11a/b/g
●
Intel 802.11a/b/g/n with iAMT 4.0 support
●
Intel 802.11a/b/g with iAMT support
√ √
Integrated WWAN options by way of wireless module:
Two WWAN 5-band antennas built into display
assembly
√ √
4 Chapter 1 Product description

HP 2510p - Compaq Business Notebook Specifications

General

Display	12.1-inch WXGA (1280 x 800)
Graphics	Intel GMA X3100
Processor	Intel Core 2 Duo U7600
RAM	Up to 4 GB DDR2 SDRAM, 667 MHz
Storage	80/120 GB 5400 RPM
Operating System	Windows Vista Business
Battery Life	Up to 6 hours
Wireless	Intel PRO/Wireless 3945ABG or 4965AGN
Dimensions	28.2 x 21.4 x 2.35 cm
Ports	3 USB 2.0, VGA, headphone/microphone jacks, docking connector
Optical Drive	External (optional)
