Item Description Spare part number
nVidia NB9P-GLM2 graphics card with 512 MB of graphics subsystem memory (supports
Quadro FX 770M)
502338-001
Plastics Kit (see Plastics Kit on page 26 for more Plastics Kit spare part information): 495076-001
(9a) ExpressCard slot protective insert
(9b) Memory module compartment cover
(9c)
Bluetooth module cover
(9d) Hard drive cover
Base enclosure rubber screw covers (2, not illustrated)
Computer feet (4, not illustrated)
(10)
Processor
Intel Core2 Extreme processors
QX9300, 2.53-GHz Quad Core processor (12-MB L2 cache, 1066-MHz FSB) 507946-001
X9100, 3.06-GHz processor (6-MB L2 cache, 1066-MHz FSB) 507950-001
Intel Core2 Quad processors
Q9100, 2.26-GHz processor (6-MB L2 cache, 1066-MHz FSB) 507947-001
Q9000, 2.0-GHz processor (6-MB L2 cache, 1066-MHz FSB) 507948-001
Intel Core2 Duo processors
T9900, 3.06-GHz processor (6-MB L2 cache, 1066-MHz FSB) 570434-001
T9800, 2.93-GHz processor (6-MB L2 cache, 1066-MHz FSB) 507951-001
T9600, 2.8-GHz processor (6-MB L2 cache, 1066-MHz FSB) 507955-002
T9550, 2.66-GHz processor (6-MB L2 cache, 1066-MHz FSB) 507953-001
T9400, 2.53-GHz processor (6-MB L2 cache, 1066-MHz FSB) 507956-002
P9600, 2.66-GHz processor (3-MB L2 cache, 1066-MHz FSB) 507957-001
P9500, 2.53-GHz processor (3-MB L2 cache, 1066-MHz FSB) 507958-001
P8800, 2.66-GHz processor (3-MB L2 cache, 1066-MHz FSB) 570036-001
P8700, 2.53-GHz processor (3-MB L2 cache, 1066-MHz FSB) 507960-001
P8600, 2.4-GHz processor (3-MB L2 cache, 1066-MHz FSB) 507963-002
P8400, 2.26-GHz processor (3-MB L2 cache, 1066-MHz FSB) 507964-002
(11) Modem module
NOTE: The modem module spare part kit does not include a modem module cable. The
modem module cable is included in the Cable Kit, spare part number 495064-001. See
Cable
Kit on page 27 for more Cable Kit spare part number information.
(12) SIM
(13) System board
For use in all countries and regions except Russia and China:
24 Chapter 3 Illustrated parts catalog
