HP 27MQ User Manual

10
RC
Before removing the RC, follow these steps:
▲ Prepare the monitor for disassembly. See Preparation for disassembly on page 9.
Step
Figure
Description
1．Preparation
and remove the
stand-base
ass'y
Lay the monitor
on a flat, soft
and clean
surface.
Remove the
screws to
remove the
stand-base
assy.
2．Remove the
rear cover
Remove the
rear cover
3. Disconnect
the cable and
the tape
Disconnect the
cable and the
tape

HP 27MQ Specifications

General

Pixel pitch	0.233 x 0.233 mm
Screen shape	Flat
Backlight type	LED
Display diagonal	27 \
Display technology	LCD
Native aspect ratio	16:9
Maximum refresh rate	60 Hz
Contrast ratio (typical)	1000:1
Display number of colors	-
Digital vertical frequency	0 - 60 Hz
Digital horizontal frequency	0 - 80 kHz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1024 x 768 (XGA)
HDMI	Yes
DisplayPorts quantity	0
AC input voltage	100 - 240 V
Power consumption (standby)	0.5 W
Power consumption (typical)	32 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Package depth	234 mm
Package width	705 mm
Package height	478 mm
Package weight	9270 g
Tilt angle range	-5 - 23 °
Panel mounting interface	100 x 100 mm
Product color	Black, Silver

Weight and Dimensions

Depth (with stand)	211.6 mm
Height (with stand)	504.9 mm
Weight (with stand)	6840 g
Depth (without stand)	50.5 mm
Width (without stand)	614.2 mm
Height (without stand)	367.9 mm
Weight (without stand)	6.84 g
