11
4. Disconnect
the tapes and
remove the
screws. Remove
the Led Board
Disconnect the
tapes and
remove the
screws.
Remove the
LED Board
5. Remove the
screws and
disconnect the
pins.
\
Remove the
screws and
disconnect the
pins.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP 27MQ and is the answer not in the manual?

HP 27MQ Specifications

General IconGeneral
Pixel pitch0.233 x 0.233 mm
Screen shapeFlat
Backlight typeLED
Display diagonal27 \
Display technologyLCD
Native aspect ratio16:9
Maximum refresh rate60 Hz
Contrast ratio (typical)1000:1
Display number of colors-
Digital vertical frequency0 - 60 Hz
Digital horizontal frequency0 - 80 kHz
Display brightness (typical)300 cd/m²
Supported graphics resolutions1024 x 768 (XGA)
HDMIYes
DisplayPorts quantity0
AC input voltage100 - 240 V
Power consumption (standby)0.5 W
Power consumption (typical)32 W
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)20 - 80 %
Package depth234 mm
Package width705 mm
Package height478 mm
Package weight9270 g
Tilt angle range-5 - 23 °
Panel mounting interface100 x 100 mm
Product colorBlack, Silver
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)211.6 mm
Height (with stand)504.9 mm
Weight (with stand)6840 g
Depth (without stand)50.5 mm
Width (without stand)614.2 mm
Height (without stand)367.9 mm
Weight (without stand)6.84 g
