Bottom
Component Description
(1) Battery lock Locks the battery in the battery bay.
(2) Battery release latch Releases the battery.
(3) Vent Enables airow to cool internal components.
NOTE: The computer fan starts up automatically to cool
internal components and prevent overheating. It is normal
for the internal fan to cycle on and o during routine
operation.
(4) Speakers (2) Produce sound.
12 Chapter 2 External component identication
