System board
NOTE: The system board spare part kit includes replacement thermal materials.
Description Spare part number
System board (includes replacement thermal materials):
All system boards use the following part numbers:
xxxxxx-001: Windows 7 or non-Windows operating systems
xxxxxx-601: Windows 10 operating system
For use in HP Notebook PC models with UMA graphics memory
●
Intel Core i7-6500U processor (full featured models) 845206-xxx
●
Intel Core i7-6500U processor (defeatured models) 855545-xxx
●
Intel Core i5-6200U processor (full featured models) 845205-xx1
●
Intel Core i5-6200U processor (defeatured models) 855544-xx1
●
Intel Core i3-6100U processor (full featured models) 845204-xx1
●
Intel Core i3-6100U processor (defeatured models) 855543-xx1
●
Intel Celeron 3855U processor (full featured models) 845203-xx1
●
Intel Celeron 3855U processor (defeatured models) 855542-xx1
●
Intel Celeron 3215U processor 845202-xx1
For use in HP Notebook PC models with 2 GB of discrete graphics memory
●
Intel Core i7-6500U processor (full featured models) 845201-xx1
●
Intel Core i7-6500U processor (defeatured models) 854105-xx1
●
Intel Core i7-5500U processor 855546-xx1
●
Intel Core i5-6200U processor (full featured models) 845200-xx1
●
Intel Core i5-6200U processor (defeatured models) 855541-xx1
●
Intel Core i5-5200U processor 845199-xx1
●
Intel Core i3-6100U processor (full featured models) 845198-xx1
●
Intel Core i3-6100U processor (defeatured models) 855540-xx1
●
Intel Core i3-5005U processor 845197-xx1
●
Intel Celeron 3855U processor 845196-xx1
Before removing the system board, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
Component replacement procedures 53
