Chapter 3 Replacing Assemblies
Tools Required
Assembly-Level Service Guide 3-3
3
Tools Required
The following tools are required for these removal and replacement
procedures:
• Hand TORX®‚ 10 screwdriver (T10)
• Hand TORX®‚ 15 screwdriver (T15)
• 7-mm spin tight
• 14-mm deep-socket spin tight
• Soldering iron—for removing Option 060 Rear Terminals
• Small (1 point) Pozidriv screwdriver—for removing Option 010/012
oven oscillator from A6 Timebase Support Board
Do This First
Before performing any of the removal and replacement procedures, the
following steps must be performed.
1 Turn Counter off.
2 Remove ac line power cord from the rear ac line socket.
