Chapter 5 Replaceable Parts
Cabinet Parts and Hardware
5-6 Assembly-Level Service Guide
5
Cabinet Parts and Hardware
To locate and identify miscellaneous cabinet and chassis parts and
instrument hardware, refer to Figure 2-8A, Figure 2-8B, and Figure 5-1.
These figures provide different views of the instrument, with the parts
identified by reference designations; the reference designations
correspond with the ones in Table 5-3.
Table 5-2. Reference Designation
A=assembly
H = hardware
J = electrical connector
(stationary portion); jack
MP= miscellaneous mechanical part
P = electrical connector
(movable portion); plug
P/O= part of
S = switch
T=transformer
TP = test point
U = integrated circuit; microcircuit
W = cable; transmission path; wire
