HP 7 Pro 740pm Series User Manual

17
Connector repair
This procedure includes HDMI, Display Port, Mini Display Port, USB-C LAN and USB-A connectors.
The connectors are on the main board (board part number 7ZB.04C01.0011).
The connector identifiers are as follows:
Connector
Location
HDMI
HDMI1
DP
DP1
USB-C
SKT1, SKT2
LAN
RJ1
USB-A
USB3, USB4
Before repairing connectors, follow these steps:
▲ Prepare the monitor for disassembly. See Preparation for disassembly on page 11.
HDMI connector HDMI1
Repair the HDMI connector:
1) Use a soldering iron and a de-soldering pump to remove as much solder as possible from the pin.
