Table 1-4. Recommended Test Equipment (continued)
Instrument
Counters
Frequency standard
Critical Specifications
for Equipment Substitution
Output frequency: 10 MHz
Accuracy: <l x 10-l’
Recommended
Use
Model
HP 5061B
PA
Microwave frequency counter
Universal counter
Frequency range: 9 MHz to 7 GHz HP 5343A OR
PAT,
External frequency reference input HP 5350B*
WV
Timebase accuracy (aging): <5 x lo-“/day Option 001
Modes: TI A+B, frequency count HP 5334A/B P
Time interval measurement range: 100 ns to 120 s
Frequency count range: 400 Hz to 11 MHz
Frequency resolution: 1 mHz
Timebase accuracy (aging): <3 x 10m7/month
External 10 MHz reference input
Receivers
spectrum analyzer Frequency range: 300 kHz to 7 GHz
Amplitude range: -70 dBm to +20 dBm
HP 8566B*
A,T
VIeasuring receiver Compatible w/power sensors
dB relative mode
Resolution: 0.01 dB
Reference accuracy: <fl.2%
HP 8902A*
PAT,
WV
iensors
‘ower sensor Frequency range: 10 MHz to 13.2 GHz
Maximum SWR:
1.40 (10 to 30 MHz)
1.18 (30 to 50 MHz)
1.10 (50 MHz to 2 GHz)
1.18 (2 to 13.2 GHz)
HP 8481A+
PAT,
WV
‘ower sensor
Frequency range: 250 MHz to 350 MHz
Power range: 100 nW to 10 PW
Maximum SWR: 1.15 (250 to 350 MHz)
Frequency range: 100 kHz to 2.9 GHz
Maximum S WR:
1.1 (1 MHz to 2.0 GHz)
1.30 (2.0 GHz to 2.9 GHz)
HP 8481D
P,A
‘ower sensor
HP 8482A*
PAT,
WV
’ Part of microwave workstation
’ = performance tests; A = adjustments; M = test & adjustment module; T = troubleshooting;
J = operation verification
