Chapter 5, Advanced Operations
Status Reporting
Table 22 shows the Hardware Status Register Group #2’s Condition Register bit
assignments.
Table 22 Hardware Status Register Group #2, Condition Register Bit Assignments
Bit
Number
Binary
Weighting
Condition Comment
15 32768 Not Used (Always 0) Defined by SCPI Version 1994.0
14 16384 Unused in Test Set
13 8192 Unused in Test Set
12 4096 Unused in Test Set
11 2048 Inconsistent ACP Channel Bandwidth and
Resolution Bandwidth
10 1024 ACP Channel Bandwidth or Channel Offset
Too Wide
9 512 AFGen1 Frequency Exceeds Variable
Frequency Notch Filter Range
8 256 Requested Audio Voltage Too Large for
AFGen2
7 128 Requested FM Deviation Too Large for RF
Generator Frequency
6 64 Requested Simultaneous AM and FM
Modulation
Simultaneous AM and FM
modulation is not allowed.
5 32 Audio Input Level Auto Ranging Error
4 16 RF Input Level Auto Ranging Error
3 8 RF Input Frequency Auto Tuning Error
2 4 RF Gen/RF Anl/RF Offset Frequency
Combination Not Possible
(RF Gen Tune Freq) - (RF Anal
Tune Freq) not equal to (RF Offset
Freq)
1 2 RF Generator Amplitude Level Too High for
Selected Output Port
0 1 Spectrum Analyzer Reference Level Too High/
Low For Selected Input Port
