Chapter 3, HP-IB Command Guidelines
Guidelines for Operation
HP-IB Units (UNITs)
HP-IB Units are the units-of-measure used by the Test Set when sending numeric
data (field settings and measurement results) through HP-IB, and the default
units-of-measure for receiving numeric data (field settings and measurement
results) through HP-IB. Changing HP-IB Units has no affect on the Display Units
or Attribute Units settings. Table 7 lists the HP-IB Units used in the Test Set.
Use the UNITs? command to determine the HP-IB Units for a measurement result
or field setting (refer to
"Reading-Back HP-IB Units." on page 72 for more
information).
Table 7 HP-IB Units
Parameter Unit of Measure
Power Watts (W) or dBm (DBM)
Amplitude Volts (V), or dBµV (DBUV)
Frequency Hertz (Hz)
Frequency Error Hertz (HZ) or parts per million (PPM)
Time Seconds (S)
Data Rate Bits per second (BPS)
Current Amperes (A)
Resistance Ohms (OHM)
Relative Level decibels (DB) or percent (PCT)
Marker Position Division (DIV)
FM Modulation Hertz (HZ)
AM Modulation Percent (PCT)
