71
Chapter 3, HP-IB Command Guidelines
Guidelines for Operation
Changing HP-IB Units. Use the UNITs command to change the HP-IB Units
setting for selected measurement or instrument setup fields. Only the HP-IB units
for power, relative level, and frequency error can be changed. Table 8 lists the
measurement and instrument setup fields which have changeable HP-IB Units.
For example, the following BASIC language program statements change the
HP-IB Units for the
TX Power measurement from W to dBm:
OUTPUT 714;"MEAS:RFR:POW:UNIT DBM"
Table 8 HP-IB Units That Can Be Changed
Function Available HP-IB Units
TX Power measurement W or DBM
Adjacent Channel Power
LRATio, URATio DB or PCT
LLEVel, ULEVel W or DBM
SINAD measurement DB or PCT
DISTN measurement DB or PCT
SNR measurement DB or PCT
RF Generator Amplitude W or DBM or V or DBUV
Frequency Error HZ or PPM
