2-4
9845B/C
Environmental,
Installation,
and
Preventive
Maintenance
Requirements
The sliding lock handles! -
on
each leg of the display - should be pulled out
(in
the open
position).
Working
on
one
leg at a time, tilt the display slightly to the right
and
gUide
the right leg into
place. Pull the display to the left toward the other leg, and position the left leg into place.
The back of both display legs should now
be
resting on the top cover of the mainframe. (If not,
check both sliding lock handles - they should
be
pulled out.) There should
be
a gap (about %
inch) between the mainframe top cover and the front of the display legs. If the display does not
appear
to
be
sitting properly
on
the mainframe, repeat the previous step.
v."
1 Ignore
the
references
to
the
sliding lock
handles
if
the
9845C
is
not
equipped
with
the
sliding lock
mechanism
