REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés per un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
piéce portant le numéro spécifié.
A4576
<SPARK GAP>
SG101 1-517-499-21 GAP, SPARK
SG201 1-517-499-21 GAP, SPARK
SG301 1-517-499-21 GAP, SPARK
SG401 1-519-526-11 LAMP, NEON
SG402 1-519-422-11 GAP, SPARK
SG403 1-519-526-11 LAMP, NEON
<SOCKET>
SK401¡1-251-640-11SOCKET, PICTURE TUBE
*******************************************************************************
* 8-933-269-00 GA BOARD, COMPLETE
******************************
<CAPACITOR>
C7501 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C7502 1-136-169-00 FILM 0.22MF 5% 50V
C7503 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C7504 1-136-165-00 FILM 0.1MF 5% 50V
C7505 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C7506 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
<CONNECTOR>
CN7501*1-774-512-11CONNECTOR, BPARD TO BOARD 10P
<DIODE>
D7501 8-719-110-57 ZENER DIODE RD22ESB2
D7502 8-719-911-19 DIODE 1SS119-25
<IC>
IC7501 8-759-482-62 IC MC33262P
<TRANSISTOR>
Q7501 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q7502 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q7503 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q7504 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
<RESISTOR>
R7501 1-216-025-91 RES, CHIP 100
R7502 1-216-073-00 RES, CHIP 10K
R7503 1-216-041-00 RES, CHIP 470
R7504 1-216-675-11 METAL CHIP 10K 0.50%1/10W
R7505 1-216-673-11 METAL CHIP 8.2K 0.50%1/10W
R7506 1-216-073-00 RES, CHIP 10K
R7507 1-216-089-91 RES, CHIP 47K
R7508 1-216-073-00 RES, CHIP 10K
R7509 1-216-073-00 RES, CHIP 10K
R7510 1-216-073-00 RES, CHIP 10K
R7511 1-216-073-00 RES, CHIP 10K
R7512 1-216-089-91 RES, CHIP 47K
R7513 1-216-093-00 RES, CHIP 68K
*********************************************************************************
* 8-933-277-00 G BOARD, COMPLETE
****************************
4-382-854-11 SCREW (M3X10), P, SW (+)
(IC660,Q610,Q640,D610,D611,D672)
* 7-322-065-72 RUBBER, RTV (SE-9168) (130G)
(R640,C671,C682,VDR640)
<CAPACITOR>
C601 ¡ 1-113-900-51 CERAMIC 470PF 10% 250V
C602 ¡ 1-113-900-51 CERAMIC 470PF 10% 250V
C603 ¡ 1-107-533-51 FILM 1MF 20% 250V
C604 ¡ 1-107-533-51 FILM 1MF 20% 250V
C605 ¡ 1-113-926-91 CERAMIC 0.0047MF 250V
C606 ¡ 1-113-926-91 CERAMIC 0.0047MF 250V
C607 1-113-900-11 CERAMIC 470PF 10% 250V
C610 1-137-479-11 FILM 1MF 10% 400V
C611 1-117-849-11 ELECT 330MF 20% 450V
C612 1-126-959-11 ELECT 0.47MF 20% 50V
C616 1-107-888-11 ELECT 47MF 20% 25V
C640 1-165-127-11 CERAMIC 470PF 10% 500V
C641 1-165-127-11 CERAMIC 470PF 10% 500V
C642 1-136-171-00 FILM 0.33MF 5% 50V
C643 1-136-171-00 FILM 0.33MF 5% 50V
C644 1-165-127-11 CERAMIC 470PF 10% 500V
C645 1-136-167-00 FILM 0.15MF 5% 50V
C646 1-136-167-00 FILM 0.15MF 5% 50V
C647 1-129-719-00 FILM 0.027MF 5% 630V
C660 1-111-057-11 ELECT 120MF 20% 25V
C661 1-128-526-11 ELECT 100MF 20% 16V
C662 1-137-399-11 FILM 0.1MF 5% 50V
C663 1-126-965-11 ELECT 22MF 20% 50V
C670 1-137-370-11 FILM 0.01MF 5% 50V
C671 1-107-966-51 ELECT 220MF 20% 250V
C672 1-107-959-11 ELECT 3.3MF 20% 250V
C673 1-107-935-11 ELECT 330MF 20% 100V
C674 1-107-928-11 ELECT 4.7MF 20% 100V
C675 1-107-890-11 ELECT 2200MF 20% 25V
C676 1-107-888-11 ELECT 47MF 20% 25V
C677 1-107-890-11 ELECT 2200MF 20% 25V
C678 1-107-888-11 ELECT 47MF 20% 25V
C679 1-126-927-11 ELECT 2200MF 20% 10V
C680 1-126-927-11 ELECT 2200MF 20% 10V
C681 1-107-905-11 ELECT 4.7MF 20% 50V
(a)(ga)(g)
7-5
