HP A4576 User Manual

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés per un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
piéce portant le numéro spécifié.
A4576
C682 1-126-963-11 ELECT 4.7MF 20% 50V
C683 1-164-646-11 CERAMIC 2200PF 10% 500V
C684 1-137-370-11 FILM 0.01MF 5% 50V
C685 1-107-909-11 ELECT 47MF 20% 50V
C690 1-107-888-11 ELECT 47MF 20% 25V
C691 1-107-888-11 ELECT 47MF 20% 25V
C692 1-111-016-11 ELECT 0.0012F 20% 10V
C693 1-137-399-11 FILM 0.1MF 5% 50V
C695 1-164-644-11 CERAMIC 330PF 10% 500V
C697 1-136-165-00 FILM 0.1MF 5% 50V
<CONNECTOR>
CN603*1-580-689-11 PIN, CONNECTOR (PC BOARD) 4P
CN604 1-691-960-11 PIN, CONNECTOR (PC BOARD) 3P
CN605 1-691-960-11 PIN, CONNECTOR (PC BOARD) 3P
CN610*1-774-511-11 CONNECTOR, BOARD TO BOARD 10P
CN671*1-564-514-11 PLUG, CONNECTOR 11P
CN672*1-564-512-11 PLUG, CONNECTOR 9P
CN673*1-564-508-11 PLUG, CONNECTOR 5P
<DIODE>
D610 ¡ 8-719-510-53 DIODE D4SB60L
D611 8-719-029-04 DIODE D5L60
D612 8-719-304-63 DIODE RM11C
D613 8-719-110-49 ZENER DIODE RD18ESB2
D614 8-719-977-28 ZENER DIODE DTZ10B
D617 8-719-404-49 DIODE MA111
D640 8-719-404-49 DIODE MA111
D660 8-719-059-23 DIODE P6KE200AG23
D661 8-719-979-64 DIODE UF4005PKG23
D662 8-719-058-91 DIODE AG01A-V0
D663 8-719-110-31 ZENER DIODE RD12ESB2
D666 8-719-109-93 ZENER DIODE RD6.2ESB2
D670 8-719-064-49 DIODE D4SBL40
D671 8-719-510-64 DIODE S2LA20F
D672 8-719-052-91 DIODE D4SBS4-F
D673 8-719-022-97 DIODE D2S4MF
D674 8-719-022-97 DIODE D2S4MF
D677 8-719-911-19 DIODE 1SS119-25
D678 8-719-911-19 DIODE 1SS119-25
D680 8-719-404-49 DIODE MA111
D681 8-719-404-49 DIODE MA111
D682 8-719-510-64 DIODE S2LA20F
D683 8-719-911-19 DIODE 1SS119-25
D684 8-719-110-57 ZENER DIODE RD22ESB2
D691 8-719-510-37 DIODE D5LC20U
D692 8-719-911-19 DIODE 1SS119-25
D693 8-719-404-49 DIODE MA111
<FUSE>
F601 ¡ 1-576-233-11 FUSE (H.B.C.) (6.3A/250V)
1-533-223-11 HOLDER, FUSE ; F601
<FERRITE BEAD>
FB610 1-410-396-41 INDUCTOR 0.45UH
FB611 1-410-396-41 INDUCTOR 0.45UH
FB612 1-410-396-41 INDUCTOR 0.45UH
<IC>
IC630 8-749-013-03 IC DM-60
IC660 8-759-470-64 IC TOP223Y-BB
IC690 8-749-011-42 IC SI-3050F
IC691 8-759-140-85 IC UPC1093J
<COIL>
L610 1-416-409-11 COIL, CHOKE
L611 1-411-674-11 COIL, CHOKE 68UH
L670 1-412-529-11 INDUCTOR 22UH
L671 1-412-529-11 INDUCTOR 22UH
L672 1-412-529-11 INDUCTOR 22UH
L673 1-412-529-11 INDUCTOR 22UH
L691 1-412-529-11 INDUCTOR 22UH
<PHOTO COUPLER>
PH660 8-749-010-64 PHOTO COUPLER PC123F2
PH680 8-749-010-64 PHOTO COUPLER PC123F2
<IC LINK>
PS670¡1-533-593-31LINK, IC (2A/90V AC, 60V DC)
PS671¡1-533-593-31LINK, IC (2A/90V AC, 60V DC)
PS673¡1-533-593-31LINK, IC (2A/90V AC, 60V DC)
PS674¡1-533-593-31LINK, IC (2A/90V AC, 60V DC)
<TRANSISTOR>
Q610 8-729-041-65 TRANSISTOR 2SK2195F04
Q615 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q640 8-729-041-12 TRANSISTOR MX0841AB-F
Q641 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q642 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q660 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q680 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q681 8-729-230-45 TRANSISTOR 2SC2458-YGR
Q682 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q683 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q690 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q691 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
<RESISTOR>
R601 ¡ 1-220-825-91 CARBON 330K 5% 1/2W
R604 1-260-089-11 CARBON 150 5% 1/2W
R610 1-216-383-11 METAL OXIDE 0.33 5% 3W F
R611 1-216-383-11 METAL OXIDE 0.33 5% 3W F
R612 1-215-477-00 METAL 220K 1% 1/4W
G
7-6

HP A4576 Specifications

General

Brand	HP
Model	A4576
Category	Monitor
Language	English
