HP A4576

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés per un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
piéce portant le numéro spécifié.
A4576
<RESISTOR>
R801 1-215-433-00 METAL 3.3K 1% 1/4W
R802 1-215-409-00 METAL 330 1% 1/4W
R803 1-215-409-00 METAL 330 1% 1/4W
R804 1-215-413-00 METAL 470 1% 1/4W
R805 1-215-413-00 METAL 470 1% 1/4W
R806 1-215-417-00 METAL 680 1% 1/4W
R807 1-215-421-00 METAL 1K 1% 1/4W
R808 1-215-421-00 METAL 1K 1% 1/4W
R809 1-215-429-00 METAL 2.2K 1% 1/4W
R810 1-215-433-00 METAL 3.3K 1% 1/4W
R814 1-249-429-11 CARBON 10K 5% 1/4W
R815 1-249-429-11 CARBON 10K 5% 1/4W
R818 1-215-445-00 METAL 10K 1% 1/4W
R819 1-249-441-11 CARBON 100K 5% 1/4W
R826 1-249-408-11 CARBON 180 5% 1/4W
R827 1-249-407-11 CARBON 150 5% 1/4W
<SWITCH>
S802 1-692-431-21 SWITCH, TACTILE (CONT+)
S803 1-692-431-21 SWITCH, TACTILE (CONT-)
S804 1-692-431-21 SWITCH, TACTILE (MENU)
S805 1-692-431-21 SWITCH, TACTILE (BRT+)
S806 1-692-431-21 SWITCH, TACTILE (BRT-)
S818 1-692-431-21 SWITCH, TACTILE (ASC)
S820 1-692-431-21 SWITCH, TACTILE (RESET)
<THERMISTOR>
TH801 1-807-796-11 THERMISTOR
*******************************************************************************
* 8-933-279-00 J BOARD, COMPLETE
****************************
<CONNECTOR>
CN891*1-691-961-11 PIN, CONNECTOR (PC BOARD) 2P
<SWITCH>
S891 ¡ 1-571-433-31 SWITCH, PUSH (AC POWER)
*******************************************************************************
* 8-933-263-00 L BOARD, COMPLETE
****************************
<CAPACITOR>
C5002 1-126-964-11 ELECT 10MF 20% 50V
C5003 1-126-933-11 ELECT 100MF 20% 16V
C5004 1-104-664-11 ELECT 47MF 20% 25V
C5005 1-104-664-11 ELECT 47MF 20% 25V
C5008 1-104-664-11 ELECT 47MF 20% 25V
C5009 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5101 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5103 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5104 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5105 1-104-664-11 ELECT 47MF 20% 25V
C5106 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5107 1-137-399-11 FILM 0.1MF 5% 50V
C5108 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5109 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5110 1-104-664-11 ELECT 47MF 20% 25V
C5111 1-137-399-11 FILM 0.1MF 5% 50V
C5201 1-104-664-11 ELECT 47MF 20% 25V
C5202 1-104-664-11 ELECT 47MF 20% 25V
C5203 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5204 1-137-399-11 FILM 0.1MF 5% 50V
C5205 1-164-489-11 CERAMIC CHIP 0.22MF 10% 16V
C5206 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5301 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5303 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5304 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5305 1-104-664-11 ELECT 47MF 20% 25V
C5306 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5307 1-137-399-11 FILM 0.1MF 5% 50V
C5308 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5309 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5310 1-104-664-11 ELECT 47MF 20% 25V
C5311 1-137-399-11 FILM 0.1MF 5% 50V
C5401 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5403 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C5404 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5405 1-104-664-11 ELECT 47MF 20% 25V
C5406 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5407 1-137-399-11 FILM 0.1MF 5% 50V
C5408 1-163-003-11 CERAMIC CHIP 330PF 10% 50V
C5409 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5410 1-104-664-11 ELECT 47MF 20% 25V
C5412 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5501 1-126-923-11 ELECT 220MF 20% 10V
<CONNECTOR>
CN5001*1-564-512-11PLUG, CONNECTOR 9P
CN5002*1-564-509-11PLUG, CONNECTOR 6P
CN5003 1-564-513-11PLUG, CONNECTOR 10P
CN5004*1-564-507-11PLUG, CONNECTOR 4P
<DIODE>
D5002 8-719-801-78 DIODE 1SS184
D5101 8-719-800-76 DIODE 1SS226
D5103 8-719-800-76 DIODE 1SS226
D5201 8-719-800-76 DIODE 1SS226
D5301 8-719-800-76 DIODE 1SS226
HJL
7-15
