HP A4576

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés per un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
piéce portant le numéro spécifié.
A4576
D5303 8-719-800-76 DIODE 1SS226
D5401 8-719-800-76 DIODE 1SS226
D5403 8-719-800-76 DIODE 1SS226
D5501 8-719-976-96 ZENER DIODE DTZ4.7C
<SENSOR>
GS5001*1-475-351-11SENSOR UNIT, MAGNETIC
<IC>
IC5101 8-759-822-38 IC LA6510
IC5201 8-759-803-42 IC LA6500-FA
IC5301 8-759-822-38 IC LA6510
IC5401 8-759-822-38 IC LA6510
<RESISTOR>
R5001 1-249-383-11 CARBON 1.5 5% 1/4W F
R5003 1-216-295-91 SHORT 0
R5005 1-216-689-11 RES, CHIP 39K
R5006 1-216-073-00 RES, CHIP 10K
R5007 1-216-049-91 RES, CHIP 1.0K
R5008 1-216-295-91 SHORT 0
R5009 1-216-295-91 SHORT 0
R5010 1-216-295-91 SHORT 0
R5011 1-216-073-00 RES, CHIP 10K
R5012 1-216-295-91 SHORT 0
R5013 1-216-295-91 SHORT 0
R5015 1-216-049-91 RES, CHIP 1.0K
R5101 1-249-383-11 CARBON 1.5 5% 1/4W F
R5102 1-249-383-11 CARBON 1.5 5% 1/4W F
R5108 1-216-308-00 RES, CHIP 4.7
R5109 1-216-308-00 RES, CHIP 4.7
R5110 1-216-073-00 RES, CHIP 10K
R5111 1-216-308-00 RES, CHIP 4.7
R5112 1-249-383-11 CARBON 1.5 5% 1/4W F
R5113 1-216-073-00 RES, CHIP 10K
R5114 1-249-441-11 CARBON 100K 5% 1/4W F
R5115 1-215-882-00 METAL OXIDE 22 5% 2W F
R5116 1-216-073-00 RES, CHIP 10K
R5117 1-216-308-00 RES, CHIP 4.7
R5119 1-216-073-00 RES, CHIP 10K
R5120 1-249-383-11 CARBON 1.5 5% 1/4W F
R5121 1-249-441-11 CARBON 100K 5% 1/4W F
R5122 1-215-882-00 METAL OXIDE 22 5% 2W F
R5201 1-249-383-11 CARBON 1.5 5% 1/4W F
R5202 1-249-383-11 CARBON 1.5 5% 1/4W F
R5203 1-249-383-11 CARBON 1.5 5% 1/4W F
R5204 1-249-441-11 CARBON 100K 5% 1/4W F
R5205 1-216-073-00 RES, CHIP 10K
R5206 1-215-859-00 METAL OXIDE 22 5% 1W F
R5207 1-216-073-00 RES, CHIP 10K
R5208 1-216-670-11 METAL CHIP 6.2K 0.50%1/10W
R5301 1-249-383-11 CARBON 1.5 5% 1/4W F
R5302 1-249-383-11 CARBON 1.5 5% 1/4W F
R5308 1-216-308-00 RES, CHIP 4.7
R5309 1-216-308-00 RES, CHIP 4.7
R5310 1-216-073-00 RES, CHIP 10K
R5311 1-216-308-00 RES, CHIP 4.7
R5312 1-249-383-11 CARBON 1.5 5% 1/4W F
R5313 1-216-073-00 RES, CHIP 10K
R5314 1-249-441-11 CARBON 100K 5% 1/4W F
R5315 1-215-882-00 METAL OXIDE 22 5% 2W F
R5316 1-216-073-00 RES, CHIP 10K
R5317 1-216-308-00 RES, CHIP 4.7
R5319 1-216-073-00 RES, CHIP 10K
R5320 1-249-383-11 CARBON 1.5 5% 1/4W F
R5321 1-249-441-11 CARBON 100K 5% 1/4W F
R5322 1-215-882-00 METAL OXIDE 22 5% 2W F
R5401 1-249-383-11 CARBON 1.5 5% 1/4W F
R5402 1-249-383-11 CARBON 1.5 5% 1/4W F
R5406 1-216-689-11 RES, CHIP 39K
R5407 1-216-079-00 RES, CHIP 18K
R5408 1-216-308-00 RES, CHIP 4.7
R5409 1-216-308-00 RES, CHIP 4.7
R5410 1-216-089-91 RES, CHIP 47K
R5411 1-216-308-00 RES, CHIP 4.7
R5412 1-249-383-11 CARBON 1.5 5% 1/4W F
R5413 1-216-097-91 RES, CHIP 100K
R5414 1-249-441-11 CARBON 100K 5% 1/4W F
R5415 1-215-886-11 METAL OXIDE 100 5% 2W F
R5416 1-216-077-00 RES, CHIP 15K
R5417 1-216-308-00 RES, CHIP 4.7
R5419 1-216-089-91 RES, CHIP 47K
R5420 1-249-383-11 CARBON 1.5 5% 1/4W F
R5421 1-249-441-11 CARBON 100K 5% 1/4W F
R5422 1-215-885-00 METAL OXIDE 68 5% 2W F
R5423 1-216-105-91 RES, CHIP 220K
R5501 1-216-057-00 RES, CHIP 2.2K
R5502 1-216-681-11 METAL CHIP 18K 0.50%1/10W
R5503 1-216-681-11 METAL CHIP 18K 0.50%1/10W
R5504 1-216-093-00 RES, CHIP 68K
R5505 1-216-067-00 RES, CHIP 5.6K
R5506 1-216-670-11 METAL CHIP 6.2K 0.50%1/10W
L
7-16
