Upgrading Your System
Reinstalling the Power Supply
3. Lift the handle edge of the power supply enough to allow the bail lock to be disengaged from the
bail, fold the bail lock down, and the lower the power supply back into place.
4. Alternately tighten the two captive T-15 Torx screws in the corners of the power supply.
Figure 2-25 Power Supply Screws and Handles
T15 Torx
Power Supply
Thumbscrew
Handle
T15 Torx
Thumbscrew
5. Carefully tip the workstation back to the upright position.
Chapter 2
29
