Upgrading Your System
Removing the Side Panel
Removing the Side Panel
1. Remove the two T-15 Torx thumbscrews located in the top and bottom right edge of the back side
of the workstation, as shown below.
Figure 2-6 Opened Side Panel
Side-Panel Thumbscrew
Side-Panel Hook
2
Hinge Slots
2. Remove the left side panel by grasping the back edge of the panel and rotating the panel
outward as shown above. Unhinge the panel and pull it away from the workstation. Set the
panel and its screws aside.
NOTE Only the left side panel is removed. The left side panel is the one on the left when facing the
front of the workstation.
Chapter 2
13
