HP b2600 Disassembly Procedure

HP B2600 Workstation Disassembly November 2005
Page 4
2 Workstation Disassembly Procedures
Table 2-1 lists the steps to follow to disassemble the workstation.
Table 2-1 Workstation Disassembly
1.
Remove/disengage any security devices that prohibit opening the workstation.
2.
Disconnect the power cord from the electrical outlet and then from the workstation.
3.
Disconnect all peripheral device cables from the workstation.
4.
Remove the front bezel and top cover.
Press in on both release buttons found on the ends of the bezel and pull outward from the
workstation to remove it. Next, unscrew the captive screws and pull forward on the cover and
lift it off.
5.
Disconnect all internal cables from System Board, Power Supply, and other components.
