HP BladeSystem c3000 Quickspecs

7. iLO/Onboard Administrator Port
8. iLO/Onboard Administrator Port 2 (reserved for future)
9. Power Supplies
10. Interconnect Bay 4
11. Interconnect Bay 3
What's New
What's NewWhat's New
What's New
HP BladeSystem c3000 Enclosure –
––
– Tower Model
At A Glance
At A GlanceAt A Glance
At A Glance
This document covers the HP BladeSystem c3000 enclosure only. For more information on the HP c7000 enclosure, the HP ProLiant
Server Blades, and HP BladeSystem c-Class Interconnect Components please see the following QuickSpecs:
HP c7000 Enclosure: HP ProLiant Server Blades:
http://h18000.www1.hp.com/products/quickspecs/north_america/12534.html
HP BladeSystem c-Class Interconnect QuickSpecs:
http://h18000.www1.hp.com/products/quickspecs/12524_na/12524_na.html
HP BladeSystem c-Class Infrastructure QuickSpecs:
http://h18000.www1.hp.com/products/quickspecs/12517_na/12517_na.html
HP BladeSystem c7000 Enclosure QuickSpecs:
http://h18000.www1.hp.com/products/quickspecs/12810_na/12810_na.html
HP BladeSystem solutions start with a either a c7000 or c3000 Enclosure. For the c3000 Enclosure, customers can add c3000
power supplies, Active Cool Fans, a c3000 DVD drive, and if needed, an optional local KVM module. Once the enclosure has been
selected, the following components can be added: networking interconnect modules, HP ProLiant and Integrity Server Blades, and
optional Insight Control Environment for BladeSystem management software. Please reference the QuickSpecs listed above.
HP BladeSystem c3000 Enclosures:
Offered in two different models: the c3000 Enclosure for racking in standard 19 inch racks, or the c3000 Tower Enclosure on
casters for sites without racks.
Server blades, storage blades, interconnect modules, power supplies, fans, and Onboard Administrator modules are designed
to fit into the c3000 enclosure.
The HP BladeSystem c3000 enclosure is:
A single-phase enclosure available for use with in-rack PDUs & UPSs which accept C13/C14 power cords; or
Alternatively, with low-line (100VAC to 110VAC) power outlets, the enclosure's power supplies can be connected
directly to low-line wall outlets.
NOTE:
NOTE: NOTE:
NOTE: Caution: when connecting directly to wall outlets, customers should determine the maximum amperage
of the wall outlet circuit to prevent power overload. See Technical specification section in this document for the
individual power supply amperage.
HP BladeSystem c3000 enclosure options:
Optional c3000 AC power supplies (up to 6 total)
Optional c-Class Active Cool fans (between 4 and 6 total)
Optional KVM module
Optional DVD drive (if not part of an enclosure bundled part number)
Optional Rack rails (if not part of an enclosure bundled part number)
The c3000 enclosure is 6U and holds up to 8 HP c-Class server blades:
Up to 8 half-height server blades (examples: HP ProLiant BL460c, BL465c Server Blade)
Up to 4 full-height server blades (Examples: HP ProLiant BL480c, BL 680c G5, BL685c Server Blades)
Up to 4 HP SB40c Storage blades attached to half-height server blades
Up to 4 PCI Expansion blades attached to half-height server blades
Or combinations of the above.
For additional server & storage blade information, please visit:
QuickSpecs
HP BladeSystem c3000 Enclosure
HP BladeSystem c3000 EnclosureHP BladeSystem c3000 Enclosure
HP BladeSystem c3000 Enclosure
Overview
DA - 12790 North America — Version 7 — February 11, 2008 Page 2
