Using Your CD-ROM Drive
2–4
Table 2–1. CD-ROM Drive Operating Controls and Features
Control/Feature Purpose
Load/Eject Button Press the Eject Button to eject the disc tray. When the drive is in
use, you must unmount the disc before ejecting it. Refer to
“Unmounting a CD-ROM disc” later in this chapter for
instructions on Unmounting a disc.
Busy Indicator The Busy Indicator lights during a data access operation and
blinks during a data transfer. The indicator stays out when there is
one of the following:
•
Defective disc
• Disc insertion error (for example, an upside-down disc)
• No disc present
Disc Loading Tray Tray for loading the disc. Eject the disc tray to insert or remove a
disc. The tray does not open if the drive power is off.
Emergency Eject By inserting the end of a paper clip, you can eject the disc tray if
the workstation does not have power.
Headphone
Jack
Provides for the use of headphones
V
olume Control
Adjusts headphone volume
