HP Color LaserJet 9500 User Manual

174 Removal and replacement ENWW
Delivery head motor
1 Remove the back cover. See page 162.
2 On the back of the 8-bin mailbox, disconnect one cable connector (callout 1).
Figure 149. Delivery head motor (1 of 2)
3 Remove two screws (callout 2).
Figure 150. Delivery head motor (2 of 2)
4 Remove the delivery head motor.
1
2

HP Color LaserJet 9500 Specifications

General

Print Speed (Black)	Up to 24 ppm
Print Speed (Color)	Up to 24 ppm
Print Resolution (Black)	Up to 600 x 600 dpi
Print Resolution (Color)	Up to 600 x 600 dpi
Standard Memory	128 MB
Standard Paper Capacity	1, 100 sheets
Compatible Printers	HP Color LaserJet 9500 series
Type	Toner Cartridge
Media Types	Plain, bond, glossy, labels, transparencies, envelopes, cardstock
Media Sizes	Letter, legal, executive
Connectivity	Ethernet
Category	Printer
Color	Cyan, Magenta, Yellow, Black
