Pickup-and-feed system
The pickup-and-feed system picks up and feeds the print media. It consists of several types of feed
rollers.
Figure 5-21 Pickup-and-feed system
YMCK
YMC K
Number Description Number Description
SR1 Paper feeder pre-registration
sensor
M1 Drum motor
SR4 Registration sensor M3 Registration motor
102 Chapter 5 Theory of operation ENWW
