Table 8-13 Internal components (7 of 7)
Ref Description Part number Qty
1 Cover, upper rear RL1-1823-000CN 1
2 Cover, lower rear RC2-3748-000CN 1
3 Cap, link RC2-3774-000CN 2
4
Link, guide
1
Not orderable 1
5 Link, door RC2-3750-000CN 2
6
Paper feed guide assembly (simplex and duplex products)
2
RM1-4838-000CN 1
7 Rear door rib assembly RM1-4876-000CN 1
9 Paper re-pickup guide assembly RM1-4877-000CN 1
10 Rear door assembly RM1-4878-000CN 1
11 Duplexing-feed guide assembly RM1-4879-000CN 1
12 Reverse drive assembly RM1-4880-000CN 1
1
Depending on which end of the link-guide attachment point has failed, replace either the duplexing-feed guide assembly, or
the entire product (the interior paper guide is not replaceable).
2
The paper-feed guide includes the transfer roller.
ENWW Internal assemblies 353
