7. Slide the drive access panel toward the outside of the computer to release it and lift the access
panel off the computer.
NOTE: For easy removal, grasp the drive access panel next to the opening where the center
access panel was removed (1) when sliding it off the computer (2).
Figure 2-7 Removing the Drive Access Panel
Replacing the Drive Access Panel
1. Place the computer face down on a soft flat surface. HP recommends that you set down a blanket,
towel, or other soft cloth to protect the screen surface from scratches or other damage.
ENWW
Replacing the Drive Access Panel
17
