12. Set the hard drive cage down into the bay and slide it back toward the center of the computer
until it stops.
Figure 2-25 Installing the Hard Drive Cage
13. Tighten the captive screw to secure the hard drive cage in place.
Figure 2-26 Tightening the Hard Drive Security Screw
14. Replace the drive access panel (see Replacing the Drive Access Panel on page 17).
32 Chapter 2 Hardware Upgrades ENWW
