Removing a Bezel Blank
On some models, there is a bezel blank covering the external drive bay that needs to be removed
before installing a drive. To remove a bezel blank:
1. Remove the front bezel.
2. Push the two retaining tabs that hold the bezel blank in place towards the outer left edge of the
bezel (1) and pull the bezel blank inwards to remove it (2).
Figure 2-6 Removing a Bezel Blank
ENWW Removing a Bezel Blank 13
