7–20 437804-001 Service Reference Guide, dc5700
Removal and Replacement Procedures— Small Form Factor (SFF) Chassis
6. If you are removing an existing PCI card, hold the card at each end, and carefully rock it
back and forth until the connectors pull free from the socket. Pull the card straight up from
the socket then back towards the inside of the chassis to release it from the chassis frame. Be
sure not to scrape the card against the other components.
7. If you are removing a PXCI Express x16 card, pull the retention arm on the back of the
expansion socket away from the card and carefully rock it back and forth until the connectors
pull free from the socket. Pull the card straight up from the socket then back towards the
inside of the chassis to release it from the chassis frame. Be sure not to scrape the card
against the other components.
To complete the installation, reverse the removal procedures.

HP Compaq dc5700 MT Specifications

General

Chipset	Intel Q965 Express
Audio	Integrated High Definition audio
Network	Integrated Broadcom NetXtreme Gigabit Ethernet
Power Supply	300W
Form Factor	Microtower
Processor	Intel Pentium D, Intel Celeron D
Memory	Up to 4 GB DDR2
Graphics	Intel Graphics Media Accelerator 3000
Optical Drive	DVD-ROM
Expansion Slots	1 PCI Express x16
Ports	USB 2.0, VGA, serial, parallel
Operating System	Windows XP Professional, Windows Vista
Storage	SATA Hard Drive
