HP Compaq dc5700 MT

Service Reference Guide, dc5700 437804-001 7–25
Removal and Replacement Procedures— Small Form Factor (SFF) Chassis
7.14 Power Switc h A ssem b ly
1. Prepare the computer for disassembly (Section 7.1).
2. Remove the access panel (Section 7.3).
3. Remove the fan shroud (Section 7.11).
4. Remove the optical drive (Section 7.7.2).
5. Rotate the optical drive retainer to its upright position.
6. Disconnect the power switch/LED cable from the system board.
