Service Reference Guide, dc5700 437804-001 C–7
POST Error Messages
Network Server Mode
Active and No
Keyboard Attached
Keyboard failure while
Network Server Mode
enabled.
1. Reconnect keyboard with computer
turned off.
2. Check connector for bent or missing
pins.
3. Ensure that none of the keys are
depressed.
4. Replace keyboard.
Parity Check 2 Parity RAM failure. Run Computer Setup and diagnostic
utilities.
System will not boot
without fan.
CPU fan not installed or
disconnected in VSFF
chassis.
1. Remove the computer cover, press
the power button, and see if the
processor fan spins. If not spinning,
make sure the fan cable is plugged
onto the system board header.
Ensure the heatsink is properly
seated and installed.
2. If the fan is plugged in and the
heatsink is properly seated but the
fan does not spin, then replace the
heatsink-fan assembly.
POST Error Messages (Continued)
Screen Message Probable Cause Recommended Action

HP Compaq dc5700 MT Specifications

General

Chipset	Intel Q965 Express
Audio	Integrated High Definition audio
Network	Integrated Broadcom NetXtreme Gigabit Ethernet
Power Supply	300W
Form Factor	Microtower
Processor	Intel Pentium D, Intel Celeron D
Memory	Up to 4 GB DDR2
Graphics	Intel Graphics Media Accelerator 3000
Optical Drive	DVD-ROM
Expansion Slots	1 PCI Express x16
Ports	USB 2.0, VGA, serial, parallel
Operating System	Windows XP Professional, Windows Vista
Storage	SATA Hard Drive
