HP Compaq dc7600 SFF User Manual

Hardware Reference Guide www.hp.com 2-11
Hardware Upgrades
6. Open both latches of the memory module socket 1, then insert
the memory module into the socket 2.
Installing a DIMM
✎
A memory module can be installed in only one way. Match the notch
on the module with the tab on the memory socket.
✎
For maximum performance, populate the sockets so that the memory
capacity of Channel A is equal to the memory capacity of Channel B.
For example, if you have one preinstalled DIMM in socket XMM1
and are adding a second DIMM, it is recommended that you install a
DIMM of equal memory capacity into the XMM3 or XMM4 socket.
7. Push the module down into the socket, ensuring that the module
is fully inserted and properly seated. Make sure the latches are in
the closed position 3.

HP Compaq dc7600 SFF Specifications

General

Processor Speed	Up to 3.8 GHz
Memory	Up to 4 GB DDR2 SDRAM
Form Factor	Small Form Factor (SFF)
Power Supply	240W
Processor	Intel Pentium 4, Intel Celeron D
Storage	Up to 250 GB SATA HDD
Graphics	Intel Graphics Media Accelerator 950
Optical Drive	DVD-ROM, DVD\u00b1RW
Network	Integrated Gigabit Ethernet
Expansion Slots	1 low-profile PCI Express x16, 1 low-profile PCI Express x1, 1 low-profile PCI
Ports	USB 2.0, serial, parallel, PS/2, VGA
Operating System	Windows XP Professional
Chipset	Intel 945G Express Chipset
