Hardware Reference Guide www.hp.com 2-13
Hardware Upgrades
Installing an Expansion Card
The computer has two standard PCI expansion slots that can
accommodate an expansion card up to 17.46 cm (6.875 inches)
in length. The computer also has one PCI Express x1 expansion slot
and one PCI Express x16 expansion slot.
The PCI and PCI Express slots support only low profile cards unless
an optional riser is installed. The optional riser supports two full
height standard PCI slots. If the riser is installed, the PCI Express x16
expansion slot is inaccessible.
Expansion Slot Locations
You can install a PCI Express x1, x4, x8, or x16 expansion card in the
PCI Express x16 expansion slot.
Item Description
1 PCI expansion slot
2 PCI expansion slot
3 PCI Express x16 expansion slot
4 PCI Express x1 expansion slot
