Service Reference Guide, dx7300 433611-001 7–23
Removal and Replacement Procedures— Slim Tower (ST) Chassis
23. Rotate the drive cage back down to its normal position. Be sure to use proper cable handling
and placement precautions.
Ä
CAUTION: Cables are very sensitive. Overbending, creasing, or pinching can damage cables.
24. Replace the fan shroud on top of the fan.
25. Replace the computer cover.
