Removal and Replacement Procedures
Maintenance and Service Guide 5–19
3. Remove the three PM2.0×4.0 screws 1 and the PM2.0×3.0
screw 2 that secure the keyboard to the notebook.
4. Lift the back edge of the keyboard and swing it forward
until it rests on the palm rest 3.
Releasing the Keyboard
