5–30 Maintenance and Service Guide
Removal and Replacement Procedures
5.13 Top Cover
1. Prepare the notebook for disassembly (Section 5.3)
and remove the following components:
❏ Keyboard cover (Section 5.7)
❏ Keyboard (Section 5.8)
❏ Switch board (Section 5.9)
❏ Speakers (Section 5.10)
❏ Optical drive (Section 5.11)
❏ Display assembly (Section 5.12)
2. Turn the notebook upside-down with the front panel
toward you.
Top Cover Spare Part Number Information
For use on HP Pavilion ze4900 notebook models
For use on HP Compaq nx9040 notebook models
For use on HP Compaq nx9030 and nx9020 notebook models
For use on Compaq Presario 2200 notebook models
371799-001
373291-001
371801-001
371800-001
