5–38 Maintenance and Service Guide
Removal and Replacement Procedures
5.16 Wireless Button Board
1. Prepare the notebook for disassembly (Section 5.3)
and remove the following components:
❏ Keyboard cover (Section 5.7)
❏ Keyboard (Section 5.8)
❏ Switch board (Section 5.9)
❏ Speakers (Section 5.10)
❏ Optical drive (Section 5.11)
❏ Display assembly (Section 5.12)
❏ Top cover (Section 5.13)
❏ Heat sink (Section 5.14)
wireless button board Spare Part Number Information
With infrared transceiver
Without infrared transceiver
373017-001
373016-001
