5–34 Maintenance and Service Guide
Removal and Replacement Procedures
5.14 Heat Sink
1. Prepare the notebook for disassembly (Section 5.3) and
remove the following components:
❏ Keyboard cover (Section 5.7)
❏ Keyboard (Section 5.8)
❏ Switch board (Section 5.9)
❏ Speakers (Section 5.10)
❏ Optical drive (Section 5.11)
❏ Display assembly (Section 5.12)
❏ Top cover (Section 5.13)
Heat Sink Spare Part Number Information
Heat sink 371796-001
Thermal Pad Kit (not illustrated) 371809-001
To Next Page
