C–6 Maintenance and Service Guide
Screw Listing
Phillips PM1.5×5.0 Shoulder Screw and PM2.5×4.0
Screw Locations
Table C-2
Phillips PM1.5×5.0 Shoulder Screw and PM2.5×4.0 Screw
Color Qty. Length Thread
Head
Width
Silver 2 5.0 mm 1.5 mm 5.0 mm
Color Qty. Length Thread
Head
Width
Silver 4 4.0 mm 2.5 mm 4.0 mm
Where used:
1 Two Phillips PM1.5×5.0 shoulder screws that secure the hard drive bezel to
the hard drive (documented in Section 5.3)
Where used:
2 Four Phillips PM2.5×4.0 screws that secure the hard drive frame to the hard
drive (documented in Section 5.3)
