Screw Listing
Maintenance and Service Guide C–7
Phillips PM2.0×4.0 Screw Locations
Table C-3
Phillips PM2.0×4.0 Screw
Color Qty. Length Thread
Head
Width
Black 23 4.0 mm 2.0 mm 4.0 mm
Where used:
1 Two screws that secure the memory module compartment cover to
the notebook (documented in Section 5.5)
2 Two screws that secure the Mini PCI compartment cover to the
notebook (documented in Section 5.6)
3 One screw that secures the top cover to the notebook (documented in
Section 5.13)
mm
