C–8 Maintenance and Service Guide
Screw Listing
Phillips PM2.0×4.0 Screw Locations
Table C-3
Phillips PM2.0×4.0 Screw
(Continued)
Color Qty. Length Thread
Head
Width
Black 23 4.0 mm 2.0 mm 4.0 mm
Where used:
1 Three screws that secure the keyboard to the notebook (documented in
Section 5.8)
2 Two screws that secure the switch board to the notebook (documented in
Section 5.9)
✎
HP Pavilion ze4900 notebook models use only one PM2.0×4.0 screw
to secure the switch board to the notebook.
3 One screw that secures the optical drive to the notebook (documented in
Section 5.11)
mm
