Removal and Replacement Procedures
Maintenance and Service Guide 5–7
5. Remove the hard drive by following these steps:
a. Remove the two rubber screw covers 1 that conceal the
hard drive retention screws.
✎
Spare part number 371808-001 should be used to replace
the hard drive rubber screw covers.
b. Remove the two PM2.0×6.0 screws 2 that secure the
hard drive to the notebook.
c. Use the notch in the hard drive bezel to slide the hard
drive forward 3.
d. Remove the hard drive.
Removing the Hard Drive
Hard Drive Spare Part Number Information
40 GB, 5400 rpm (for use only with Asia Pacific
models)
378060-001
60-GB, 4200 rpm
40-GB, 4200 rpm
30-GB, 4200 rpm
371778-001
371777-001
371776-001
