HP Compaq NC4010 User Manual

Removal and Replacement Procedures
Maintenance and Service Guide 5–9
g. Remove the four PM2.5×4.0 screws 1 that secure the
hard drive frame to the hard drive.
h. Remove the hard drive frame 2.
i. Remove the hard drive connector 3.
Disassembling the hard drive
Reverse the above procedure to reassemble and install the
hard drive.

HP Compaq NC4010 Specifications

General

Brand	HP
Model	Compaq NC4010
Category	Laptop
Language	English
