Removal and Replacement Procedures
Maintenance and Service Guide 5–37
10. Turn the notebook right-side up, with the front facing you.
11. Open the notebook until the display assembly is in an
upright position.
12. Lift the display assembly straight up 1 to remove it.
13. If necessary, remove the left 2 and right 2 display hinge
covers from the display assembly.
✎
The display hinge covers are included in the Miscellaneous
Plastics Kit, spare part number 344411-001.
Removing the Display Assembly
Reverse the above procedure to install the display assembly.
